Image name: Lena.pgm
Original Image Format: PGM
Original Image Size: 2622159 bytes

Size after compression using my tool(without Huffman Encoding): 217268 bytes
Compression Ratio: 12.07
Size after compression using my tool and adaptive Huffman Encoding & LZ77: 39078 bytes
Compression Ratio: 67.10

Size obtained after doing standard JPEG compression: 32194 bytes
Compression Ratio: 81.45

(I have converted the PGM images to JPEG's as netscape does not display PGM images)

The Original and Reconstructed Images :-


Original Image	Image after compression and decompression

Zoomed in portions of the original and the Reconstructed images showing blocking artifacts inherent in the JPEG scheme :-
Both images are at 800% Zoom.


Zoomed in portion of original Image	Zoomed in portion of the reconstructed image

Though my JPEG implementation shows significant blocking, actual JPEG implementations are slightly better and show lesser blocking
